VIBE QM3i RICE ANALYZER
Meets Global Quality Standards and Custom Requirements​
Compliant with FDA Food Safety Modernization Act (FSMA)
The Vibe QM3i Rice Analyzer measures, counts and classifies kernel size, shape, and color.
The Vibe QM3i delivers fast absolute and accurate results- analyzing a 40g rice sample in under 30 seconds with a simple three-step process.
Designed for researchers, traders, and processors, the Vibe QM3i Analyzer provides expert-level inspection and analysis without the subjectivity or delays of manual methods.
Its advanced optical system offers exceptional resolution, ensuring higher accuracy and consistent, repeatable results compared to other instruments on the market.
PADDY BROWN MILLED/WHITE PARBOILED
SHORT/ ROUND MEDIUM LONG BASMATI
Key Benefits:
-
Reduces inspection time by a factor of 10
-
Simple 3-step process
1. Load sample 2. ‘Click’ start 3. Get results -
Results are stored in a database for traceability and further analysis
-
Integration with 3rd party instruments for higher-level data analysis: Weight scale, Moisture level monitor, Barcode reader, Information systems
-
No minimum sample size
-
No requirements for sample preparation with complicated trays
Key Features & capabilities:
-
% Broken kernel (Accuracy<0.5%)
-
Size analysis per each kernel
(Accuracy <100micron):-
Length
-
Width
-
Area
-
Length to Width Ratio
-
-
Abnormal color and damage kernel recognition:​
-
Chalky
-
Black spots
-
Yellow (Stain and damaged by heat)
-
Red (Heat damaged)
-
Green kernels
-
-
Kernel count
-
1,000 kernels weight
-
Group sizing information
Technical specification:​
-
High resolution, 12 MegaPixel industrial-grade color camera
-
No moving parts for higher reliability and maintenance-free
-
Absolute L*a*b* color scale and characterization
-
4,000 color pixels per kernel
-
Advanced controlled LED lighting for higher consistency
-
100-micron measurement accuracy
-
2% color scale accuracy ü 0.5% accuracy of broken kernel detection
-
255 X 180 mm (10” X 7.1”) Inspection area
-
Dimensions 400L X 400W X 500H mm (15.7”L X 15.7”W X 19.7”L)
Comprehensive Grain Analysis Reporting
DETAILED, FLEXIBLE REPORTING
Complete reporting for detailed analysis of your samples
The true power of Vibe Imaging Analytics is found in our powerful reporting Grain Analysis Reporting software, which allows you to explore every facet and detail of your samples. Whether you are working with rice, wheat, chickpeas, oats, sunflower seeds, or countless other grains, the Vibe QM3i Analyzer software produce results that are accurate, reliable, and reproducible time and time again- so you can be sure the analysis you run yields information you can make your decision on based on state-of-the-art technology.
Sample Image Analytics Reporting - Main Report Screen
Your main reporting screen provides a wealth of information in a single overview page so you can quickly gain an understanding of the color range, quality, consistency, and dimensions of your grain sample.
Sample Image Analytics Reporting - Per-Grain Detailed Report
The Vibe Imaging Analytics per-grain reporting provides incredible detail about the composition of your sample.
Sample Image Analytics Reporting - Statistical Sample Comprehensive Detail Report
The Vibe Imaging Analytics statistical sample report is the most detailed, granular report available for your analysis.
Customized Certificate of Analysis featuring a unique sample ID number and your company logo
